NIBCO MB00128 4770 3/4 in CPVC Full Port Slip 150# Ball Valve

Product Description

The NIBCO MB00128 is a 3/4 inch CPVC full port slip ball valve designed for water distribution systems. This valve is suitable for both hot and cold water applications with a maximum service temperature of one hundred forty degrees Fahrenheit. It features a one-piece molded CPVC body and is rated for a non-shock cold working pressure of one hundred fifty psi.

• Socket ends for easy installation
• Lever operated for straightforward functionality
• Ideal for residential and commercial applications

Product Highlights

The NIBCO CPVC ball valve provides durability and reliability in water pressure systems.

Product Information

Standard Information

• Brand: NIBCO
• MPN: MB00128

Technical Specifications

• Actuator Type: Lever Operated
• Ball Material: CPVC
• Body Material: CPVC
• Inlet to Outlet Length: 3.27 inches
• Top to Inlet Center: 1.76 inches
• Nominal Size: 3/4 inches
• Orifice Size: 0.72 inches
• Pressure Rating: 150 psi
• Temperature Rating: 140 degrees Fahrenheit
• Trim Material: PTFE Seat
• Softgoods Material: EPDM
• Series: 4770
