NIBCO INC NL95HLA T5857066LL 1 W/LOCK HDL

Product Description

The NIBCO INC NL95HLA is a two-piece ball valve within the T5857066LL series. It features a nominal size of one inch and a pressure rating of 600 psi. This valve is designed for various media including air, gas, and water, suitable for demanding applications. The valve is built to handle temperatures up to four hundred degrees Fahrenheit, making it ideal for HVAC systems and commercial processes.

• Durable bronze body with stainless steel trim
• Standard lever handle actuator for easy operation
• Dezincification resistant for long-term performance

Product Highlights

The NIBCO INC NL95HLA is engineered for reliability and efficiency in fluid management. It is applicable in light industrial processes including hot and cold domestic water systems and low-pressure steam applications.

Product Information

Standard Information

• Brand: NIBCO INC
• MPN: NL95HLA

Technical Specifications

• Actuator Type: Standard Lever Handle
• Ball Material: 316 Stainless Steel
• Body Material: Bronze
• Inlet to Outlet Length: 3.34 inches
• Top to Inlet Center: 2.38 inches
• Nominal Size: 1 inch
• Orifice Size: 1 inch
• Pressure Rating: 600 psi
• Temperature Rating: 400 degrees Fahrenheit
• Softgoods Material: PTFE
• Series: T-585-70-66
• End Style: NPT
• Port Type: Full
• Domestic/Import: Domestic
