NIBCO INC NL95HL6 T5857066LL 1/2 W/LOCK HDL

Product Description

The NIBCO INC NL95HL6 is a ball valve in a two-piece design. This valve has a nominal size of one-half inch and uses a standard lever handle for operation. It is rated for a pressure of six hundred psi and can handle temperatures up to four hundred degrees Fahrenheit. The valve is suitable for media such as air, gas, and water.

• Two-piece design with a full port.
• 316 stainless steel ball and stem.
• Blowout-proof stem for safety.

Product Highlights

This ball valve is ideal for commercial and light industrial applications. Use it for HVAC systems, low-pressure steam, and other fluid control scenarios.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Warranty: 5 years Limited

Technical Specifications

• Actuator Type: Standard Lever Handle
• Ball Material: 316 Stainless Steel
• Body Material: Bronze
• End Style: NPT
• Inlet to Outlet Length: 2.44 inches
• Media: Air/Gas/Water
• Nominal Size: 1/2 inches
• Orifice Size: 1/2 inches
• Port Type: Full
• Pressure Rating: 600 psi
• Series: T-585-70-66
• Softgoods Material: PTFE
• Temperature Rating: 400 degrees Fahrenheit
• Top to Inlet Center: 1.88 inches
• Trim Material: 316 Stainless Steel Stem
• Type: 2-Piece
