NIBCO INC NL94T05 TC580CSR25LL 3/8 THD RP BV 2PT MTG LL CS

Product Description

The NIBCO INC NL94T05 is a 2-piece ball valve. It features a three-eighths inch nominal size and is designed for a variety of applications. This valve has a pressure rating of 2000 psi. Suitable for water media, it can withstand temperatures up to 400 degrees Fahrenheit.

• Constructed from carbon steel
• Includes stainless steel ball
• Uses a locking lever handle for easy operation

Product Highlights

This ball valve is ideal for utility service and process piping applications. It meets MSS SP-110 standards, ensuring reliability and compliance in various installations.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• UPC: 039923678409

Technical Specifications

• Actuator Type: Locking Lever Handle
• Ball Material: Stainless Steel
• Body Material: Carbon Steel
• Domestic/Import: Import
• End Style: FNPT
• Inlet to Outlet Length: 2.07 in
• Media: Water
• Nominal Size: 3/8 in
• Orifice Size: 0.37 in
• Port Type: Conventional
• Temperature Rating: 400 deg F
• Top to Inlet Center: 1.76 in
• Series: TC-580-CS-R-25-LL
• Softgoods Material: PTFE
• Pressure Rating: 2000 psi
• Trim Material: Carbon Steel Stem and PTFE Seat
• Type: 2-Piece
