NIBCO INC NL94T04 TC580CSR25LL 1/4 THD RP BV 2PT MTG LL CS

Product Description

NIBCO INC NL94T04 TC580CSR25LL 1/4 THD RP BV 2PT MTG LL CS is a two-piece ball valve designed for various applications. This valve is compatible with water media and features a locking lever handle actuator. It has a pressure rating of 1000 psi and can withstand temperatures up to 400 degrees Fahrenheit.

• Pressure rating: 1000 psi (non-shock cold working pressure)
• Stainless steel ball with carbon steel body
• PTFE softgoods material

Product Highlights

This valve is suitable for process piping, utility service, and some chemical applications. The vented ball and blowout-proof stem ensure safety and reliability during operation.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• UPC: 039923678393

Technical Specifications

• Actuator Type: Locking Lever Handle
• Ball Material: Stainless Steel
• Body Material: Carbon Steel
• End Style: FNPT
• Media: Water
• Nominal Size: 1/4 in
• Orifice Size: 0.37 in
• Port Type: Conventional
• Temperature Rating: 400 deg F
• Inlet to Outlet Length: 2.07 in
• Top to Inlet Center: 1.76 in
• Series: TC-580-CS-R-25-LL
• Softgoods Material: PTFE
• Trim Material: Carbon Steel Stem and PTFE Seat
