NIBCO INC NF84C5D PC5857066NS 2 PRS BALL VALVE PXP 316SS

Product Description

The NIBCO INC NF84C5D is a two-piece ball valve from the PC-585-70-66-NS series. This valve features a nominal size of two inches with a press x female press connection. It is designed to handle a maximum pressure of 250 psi and temperature up to 250 degrees Fahrenheit. This full port valve consists of a stainless steel ball and a bronze body, offering durability and reliable performance in various applications.

• Max pressure rating of 250 psi
• Full port design for maximum flow
• 316 stainless steel trim for resistance against corrosion

Product Highlights

This valve includes a NIB-SEAL handle actuator and is suitable for both commercial and residential plumbing systems.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Type: 2-Piece

Technical Specifications

• Actuator Type: NIB-SEAL Handle
• Ball Material: Stainless Steel
• Body Material: Bronze
• Inlet to Outlet Length: 8.65 inches
• Nominal Size: 2 inches
• Orifice Size: 2 inches
• Port Type: Full
• Pressure Rating: 250 psi
• Series: PC-585-70-66-NS
• Softgoods Material: EPDM/PTFE
• Temperature Rating: 250 degrees Fahrenheit
• Top to Inlet Center: 3.51 inches
• Trim Material: 316 Stainless Steel Stem
