NIBCO INC NF84C5C PC5857066NS 1-1/2 PRS BALL VLV PXP 316SS

Product Description

The NIBCO INC NF84C5C is a two-piece ball valve designed for reliable flow control. This valve has a nominal size of one and a half inches and features a press x female press connection. It operates efficiently under a pressure rating of 250 psi and can handle temperatures up to 250 degrees Fahrenheit. Constructed with a stainless steel ball and a bronze body, this valve is suitable for various plumbing and HVAC applications.

• Pressure rating of 250 psi for safe operation
• Compact design with an inlet to outlet length of eight inches
• Blowout-proof stem for enhanced reliability

Product Highlights

The NIBCO INC ball valve incorporates a NIB-SEAL handle actuator and full port design for improved flow.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Domestic/Import: Domestic

Technical Specifications

• Actuator Type: NIB-SEAL Handle
• Ball Material: Stainless Steel
• Body Material: Bronze
• Nominal Size: 1-1/2 in
• Orifice Size: 1-1/2 in
• End Style: Female Press
• Inlet to Outlet Length: 8 in
• Pressure Rating: 250 psi
• Temperature Rating: 250 deg F
• Trim Material: 316 Stainless Steel Stem
• Softgoods Material: EPDM/PTFE
• Series: PC-585-70-66-NS
• Top to Inlet Center: 3.3 in
