NIBCO H-81415HV Press Uni-Flange Ball Valve 1-1/4 inch

Product Description

The NIBCO H-81415HV is a ball valve designed for press connections. It has a size of one and one-fourth inches and is made from forged brass. This valve features a unique rotating flange that is secured by a snap ring, ensuring stability and reliability. It includes a high flow hose drain with an attached cap and tether, making it easy to manage. The adjustable packing nut allows for maintenance and control during use. This valve is intended for non-potable water applications where robustness and flow control are required.

• Rotating flange secured by a snap ring.
• High flow hose drain with cap and tether.
• Features adjustable packing nut for maintenance.

Product Highlights

This ball valve is ideal for high velocity or standard circulators in non-potable water systems, ensuring efficient operation.

Product Information

Standard Information

• Manufacturer Part Number: H-81415HV
• Application: Non-Potable

Technical Specifications

• Valve Type: Ball Valve
• Connection Type: Press x Flanged
• Pipe Size: 1-1/4 inches
• Drain: Yes
• Height (Approximate): 3.74 inches
• Length (Approximate): 2.0 inches
• Weight (Approximate): 2.05 lb
• Width (Approximate): 4.44 inches
• Color Finish: Brass
• Material: Forged Brass
• Maximum Temperature: 250
• NSF Certified: Yes
• Maximum Pressure: 250 psi
• UL Listed: No
