NIBCO H-81404HV 1-Inch Press Uni-Flange Ball Valve

Product Description

The NIBCO H-81404HV is a one-inch press uni-flange ball valve suitable for non-potable water applications. Made from forged brass and steel, this valve features a uni-body design that enhances durability. It includes a detachable rotating flange secured by a snap ring, allowing for 360-degree rotation for better installation flexibility. The construction helps reduce the risk of electrolysis and galvanic corrosion. An adjustable packing nut is also provided to ensure a secure fit.

• Press connection type allows for easy installation.
• Rotating flange provides flexible positioning options.
• Designed specifically for non-potable water systems.

Product Highlights

This valve ensures effective isolation within plumbing systems, providing reliable performance for various applications.

Product Information

Standard Information

• Manufacturer Part Number: H-81404HV
• Product Type: Isolator

Technical Specifications

• Material: Forged Brass, Steel
• End Connection 1: Press
• End Connection 2: Flanged
• Valve Size: 1 inch
• Maximum Pressure: 250 psi
• Maximum Temperature: 250°F
• Ball Valve: Yes
• NSF Certified: Yes (NSF 372, NSF 61)
• Approximate Height: 3.13 inches
• Approximate Length: 2.0 inches
• Approximate Width: 4.0 inches
• Approximate Weight: 1.75 pounds
