Product Description
The NIBCO H-80673W is a three-quarter inch full port ball valve made from forged brass. This valve is designed with press end connections, making it suitable for residential, commercial, and industrial use. Its manual operation is facilitated by a lever handle and includes a blowout-proof stem for enhanced safety. This valve is compatible with water, oil, and gas applications. The seat is constructed from PTFE, ensuring durability and leak resistance.
- Full port design for maximum flow.
- Constructed from durable forged brass.
- Suitable for various applications including water, oil, and gas.
Product Highlights
The NIBCO H-80673W valve provides reliable functionality across multiple settings, ensuring streamlined operations whether at home or in an industrial setting.
Product Information
Standard Information
-
Brand: NIBCO
-
MPN: H-80673W
Technical Specifications
-
Valve Size: 3/4 inch
-
End Connection: Press
-
Material: Forged Brass
-
Handle Material: Aluminum
-
Handle Type: Lever
-
Valve Operation: Manual Lever Handle
-
Valve Port Opening: Full Port
-
Valve Seat Material: PTFE
-
Valve Stem: Blowout-proof
-
Maximum Temperature: 250°F
-
Pressure Class: 250#
-
Recommended Applications: Residential, Commercial, Industrial, Water, Oil, Gas
-
ANSI Certification: ANSI 61-G
-
NSF Certification: NSF Certified
-
ISO Certification: ISO 9001
-
Collection: 8067W Series
-
Height: 1.74 inches
-
Length: 3.06 inches
-
Connection Type: Press
-
Product Type: Boiler Drain Valve
-
CA Proposition 65 Warning: WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm.
-
Country of Origin: CN
