NIBCO H-77201W-TG Thermostatic Mixing Valve

Product Description

The NIBCO H-77201W-TG is a thermostatic mixing valve made from chrome-plated forged DZR brass. This valve is built for point-of-use applications and includes features such as integral check valves and a temperature gauge. It comes factory preset to one hundred twenty degrees Fahrenheit and can maintain outlet temperatures between ninety-five and one hundred twenty degrees Fahrenheit.

• Includes integral check valves and temperature gauge.
• Factory preset to one hundred twenty degrees Fahrenheit.
• Ideal for single fixture applications.

Product Highlights

The NIBCO H-77201W-TG is designed for reliability and accuracy in temperature control for water applications.

Product Information

Standard Information

• Type: Thermostatic Mixing Valve
• Connection Type: Compression

Technical Specifications

• MPN: H-77201W-TG
• Size: 3/8 in
• Weight: 0.65 lb
• Lead Free: Yes
• Body Material: Brass
• Minimum Outlet Temperature: 95 °F
• Maximum Outlet Temperature: 120 °F
• Flow Rate @ 45 psi Pressure Loss: 4.5 gpm
• Height: 3-29/100 in
• Length: 2-27/50 in
