NIBCO H-50704W Traditional Full Port Ball Valve

Product Description

The NIBCO H-50704W is a full port ball valve made for gas, oil, and water systems. It features a forged brass body along with a quarter-turn lever handle that allows for easy operation. This valve includes PTFE soft goods and a brass stem with a PTFE ball seat trim, ensuring durability in demanding applications. Suitable for operations with a pressure rating of six hundred psi and able to withstand temperatures up to two hundred degrees Fahrenheit.

• Full port design for optimal flow.
• Quarter-turn lever handle for fast actuation.
• Constructed with reliable PTFE soft goods.

Product Highlights

This ball valve is designed to handle various media including gas, oil, and water, making it versatile for multiple applications across industries.

Product Information

Standard Information

• Brand: NIBCO
• MPN: H-50704W

Technical Specifications

• Actuator Type: Quarter Turn Lever Handle
• Body Material: Lead-Free DZR Brass
• Ball Material: Lead-Free DZR Brass
• End Style: SWT
• Inlet to Outlet Length: 3.35 inches
• Media: Gas/Oil/Water
• Nominal Size: 1 inch
• Orifice Size: 0.98 inches
• Port Type: Full
• Pressure Rating: 600 psi
• Temperature Rating: 200 degrees F
• Top to Inlet Center: 2.56 inches
• Trim Material: Brass Stem/PTFE Ball Seat
• Type: Traditional
