Nibco H-41413HV 3/4 IPS Isolator With MF DRN And Rot FLG High

Product Description

The NIBCO H-41413HV Isolator is a 3/4 IPS uni-flange ball valve designed for isolating circulator pumps in residential or commercial plumbing and heating systems. This full port forged brass valve features a rotating flange and a multi-function drain, allowing for pump replacement or service with minimal air introduction. Its design integrates multiple components into a single body, saving installation time and space. It is suitable for use with water, oil, and glycol mixes.

• Multi-Function Drain allows draining from either side of the pump.
• Rotating Flange provides precise positioning during installation.
• Easily isolates the pump for replacement and prevents electrolysis.

Product Highlights

Forged brass uni-flange ball valve with rotating flange and multi-function drain for circulator pump isolation.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: H-41413HV
• Country of Origin: China

Technical Specifications

• Part Number: H-41413HV
• Manufacturer: Nibco
• Category: Plumbing Supplies
• Subcategory: Valves
• Country of Origin: China
• Material: Brass
• Valve Type: Ball Valve
• Filter: Pneumatics, Hydraulics - Valves and Control
• Certifications: NSF/ANSI/CAN 61, NSF/ANSI 14, NSF 372, ISO 9001
• Collection: Isolator
• End Connection 1: FPT
• End Connection 2: Flanged
• End Connection 3: MGHT
• End Connections: FPT x Flanged x MGHT
• Handle Material: Enamel Coated Aluminum
• Lead Law Compliance: Not Compliant, Approved for Non-Potable Water Applications
• Maximum Operating Temperature: 300 Deg F
• Operating Temperature Range: 0 to 300 Deg F
• Maximum Pressure: 600 psi
• Pressure Class: 600#
• Recommended Application: Residential, Commercial, Plumbing, Heating
• Valve Body Style: Flanged
• Valve Disc Material: Brass
• Valve Operator: T-Handle
• Valve Port Opening: Full Port
• Valve Seat Material: PTFE
• Size: 3/4 in x 3/4 in
• Valve Stem: Blowout-proof
