NIBCO H-40624W 1 IPS LF FP BR BL VLV W/BLEEDER

Product Description

The NIBCO H-40624W is a one-inch IPS lead-free full-port brass ball valve that includes a bleeder. This valve is suitable for various applications including residential, commercial, and industrial use with water, oil, or gas. It features a blow-out proof stem ensuring safety and reliability during operation.

• Full port design allows for maximum flow efficiency.
• Incorporates a bleeder for easy purging of air or water.
• Designed for compatibility with water, oil, and gas media.

Product Highlights

This valve offers durability and high performance for any piping system needing a reliable flow control solution.

Product Information

Standard Information

• UPC: 018394003200
• Brand: NIBCO

Technical Specifications

• Nominal Size: 1 inches
• End Style: IPS
• Body Material: Forged Brass
• Port Type: Full
• Softgoods Material: PTFE
• Actuator Type: Reversible Handle
• Ball Material: HCP Brass
• Media: Gas/Oil/Water
• Series: 4062
• Temperature Rating: 100 degrees Fahrenheit
• Inlet to Outlet Length: 2-7/8 inches
• Top to Inlet Center: 2-1/2 inches
• Trim Material: Brass Stem and PTFE Seat
