NIBCO H-108G4W Forged DZR Brass In-Line Spring Loaded Check Valve Body

Product Description

The NIBCO H-108G4W features a one-inch G-Thread forged DZR brass in-line spring-loaded check valve body. This valve is ideal for various applications, including residential, commercial, and industrial settings, and can handle water, oil, or gas. It has a serviceable design with dual union ends and a stainless steel spring for durability.

• One inch G-Thread connection
• Maximum temperature of 200 degrees Fahrenheit
• Flow capacity of 8.7 Cv

Product Highlights

The valve has a self-automated check assembly that prevents back-flow, ensuring fluid moves in the desired direction. It also features dual-union ends for easy removal during servicing, making maintenance straightforward. The valve is compatible with G-Union accessories such as isolation valves and elbows.

Product Information

Standard Information

• Product Type: Check Valve
• Connection Method: Threaded

Technical Specifications

• Size: 1 inch
• Connection Type: G-Thread x G-Thread
• Maximum Temperature: 200 degrees Fahrenheit
• Flow Capacity: 8.7 Cv
• Maximum Pressure: 200 PSI
• Material: Brass
