Nibco H-10782W 1/2 PRS DZR BR IL SPRG CHK Valve

Product Description

The NIBCO H-10782W is a spring check valve with a self-automated check assembly that prevents back-flow. It is available in FIP, SWT, PRS, GMT, and PEX, and is certified to NSF/ANSI/CAN 61 & 372. Suitable for commercial, residential, heating, and plumbing applications.

• Self-Automated Check Assembly Prevents Back-Flow
• Models available to satisfy all state and federal low-lead laws
• Available in FIP, SWT, PRS, GMT, PEX

Product Highlights

This spring check valve is certified to NSF/ANSI/CAN 61 & 372 and is suitable for commercial, residential, heating, and plumbing applications.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: H-10782W
• Country of Origin: Global

Technical Specifications

• ANSI: ANSI 372, ANSI 61
• End Connection 1: Press
• End Connection 2: Press
• End Connections: Press
• FM Approved: No
• IAPMO Listed: No
• Installation Type: Vertical, Horizontal
• Lead Law Compliance Level: Lead Law Compliant and Certified
• Lead Law Compliant: Yes
• Length: 2-3/5
• Material: Brass, Stainless Steel
• Maximum Temperature: 250
• NSF: NSF 372, NSF 61
• NSF Certified: Yes
• Origin: Global
• Pressure - High: 200
• Recommended Valve Application: Commercial, Residential, Heating, Plumbing
• Type: WH10782W
• UL Listed: No
• Valve Body Material: DZR Brass
• Valve Body Style: Inline
• Valve Seat Material: Stainless Steel
• Valve Size: 1/2 in
• Valve Type: Spring Check Valve
• Width: 1-7/10
• Color Finish Name: Brass
