Nibco h-10614w 1 Inch Pex Full Port Ball Valve Dzr Brass

Product Description

The NIBCO h-10614w is a 1-inch full-port ball valve with a forged DZR brass body and PEX end connections, designed for use in residential and commercial plumbing and hydronic heating systems. Part of the Webstone Pro-Pal 1061W series, it consolidates commonly used components into a single forged brass assembly to reduce installation time and minimize space requirements. Key ratings include a 400 psi cold working pressure and a 200 degrees F temperature rating. EPDM and PTFE softgoods provide reliable sealing across the supported media range. Licensed plumbers and pipefitters are the primary installers of this valve.

This valve is rated for water, oil, and glycol mixture service, making it appropriate for potable water supply, hydronic radiant heat loops, snow-melt systems, and similar closed-loop or open-loop piping applications. The PEX end style suits residential and light commercial installs where PEX tubing is the specified distribution pipe. It is suited for both new construction and retrofit work where a compact, full-bore shutoff is required in a single assembly.

Key Features

• Full-port design minimizes flow restriction across the valve
• Forged DZR brass body resists dezincification in water service
• EPDM and PTFE softgoods compatible with water, oil, and glycol mixture
• Reversible handle accommodates varied installation orientations
• 400 psi CWP rating suits residential and commercial pressure systems
• Compact overall envelope: 3.9 inches long by 5.71 inches wide by 3.62 inches tall

Compatibility

Designed as an OEM-style replacement or new-install full-port ball valve for 1-inch PEX piping systems in residential and commercial plumbing and hydronic heating applications.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and the International Plumbing Code. Shut off system pressure and drain the line before removing any existing valve or making connections. Confirm PEX crimp, clamp, or expansion fittings are compatible with this valve end style before beginning work. Do not exceed the published pressure and temperature ratings during pressure testing or system operation.

Technical Specifications

• Nominal Size: 1 inch
• End Style: PEX
• Port Type: Full
• Pressure Rating: 400 psi CWP
• Temperature Rating: 200 degrees F
• Body Material: Forged DZR Brass
• Softgoods Material: EPDM/PTFE
• Actuator Type: Reversible Handle
• Inlet to Outlet Length: 2.75 inches
• Top to Inlet Center: 2.75 inches
• Overall Dimensions: 3.9 inches L x 5.71 inches W x 3.62 inches H
• Series: 1061W
• Media: Water, Oil, Glycol Mixture
• Origin: Import

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: h-10614w
