Nibco CD02850 Pvdf Pipe End Cap 1 Inch Sch 80 Fipt

Product Description

The NIBCO CD02850 is a 1-inch Schedule 80 PVDF end cap designed to terminate threaded pipe runs in demanding fluid-handling systems. PVDF (polyvinylidene fluoride) is a high-performance thermoplastic chosen for its resistance to aggressive chemicals, UV exposure, and elevated temperatures. The female iron pipe thread (FIPT) connection on each end allows the cap to thread directly onto male-threaded pipe or fittings. At 0.165 pounds, it is lightweight for field carrying and storage. Red coloring provides quick visual identification in multi-line piping installations. Licensed plumbers and industrial pipefitters are the typical installers.

This end cap is suited for chemical processing, ultrapure water systems, industrial plumbing, and other applications where standard thermoplastics or metal fittings are inadequate. Schedule 80 wall thickness gives the fitting the pressure rating needed for higher-demand service lines. The FIPT connection makes it compatible with standard NPT-threaded pipe assemblies. It is commonly used in both residential chemical feed lines and commercial or light-industrial process piping where corrosion resistance and chemical purity are priorities.

Key Features

• PVDF construction offers excellent chemical and UV resistance for aggressive service environments
• Schedule 80 wall thickness provides higher pressure capability compared to Schedule 40 fittings
• FIPT end connection threads directly onto standard male NPT pipe or fittings
• Red color allows fast visual identification in multi-line or color-coded piping systems
• Lightweight at 0.165 pounds, convenient for field inventory and installation

Compatibility

Designed as an OEM-style replacement or new-installation fitting for 1-inch Schedule 80 PVDF threaded pipe systems using standard NPT connections.

Installation Notes

Installation should be performed by a licensed plumber or qualified pipefitter in accordance with applicable IPC or local plumbing code requirements. Depressurize and drain the pipe system completely before removing or installing any end cap. Use PTFE thread tape or a chemical-compatible thread sealant rated for PVDF and the specific fluid being handled. Avoid over-tightening, as PVDF threads can crack under excessive torque.
