Nibco 9082880PC Copper Elbow (3/4 x 1/2, 90-Degree 1/4 Bend) PC607-4

Product Description

The Nibco 9082880PC (PC607-4) is a 90-degree copper elbow with a press connection on one end and a male NPT thread on the other, used to join 3/4 in. CTS copper tube to 1/2 in. MNPT. The press joint uses an inboard bead and EPDM O-ring compressed by a pressing tool to form a watertight seal without flame or solder. It is rated to 200 psi and -20 F to 250 F for potable and HVAC applications.

• Press connection with inboard bead and EPDM O-ring creates a watertight seal without flame, solder, or flux
• Connection types and size: 3/4 in. CTS press connection to 1/2 in. MNPT male thread (Press x MNPT)
• Ratings and compliance: 200 psi operating pressure, -20 F to 250 F temperature range; certified to NSF/ANSI/CAN-61, UPC, CSA MSE 13 and PS-117

Product Highlights

90-degree press-to-male NPT copper elbow for potable, hot, chilled and process water; EPDM O-ring seal; 200 psi, -20 F to 250 F; lead-free and dezincification resistant.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: 9082880PC
• Country of Origin: United States
