Product Description
The NIBCO 409-005 1/2 inch PVC 90-degree street elbow is designed for efficient plumbing connections. It features a male spigot and female socket connection, allowing for easy direction changes in pipe flow.
- Maximum service temperature of one hundred forty degrees Fahrenheit
- Product dimensions of four point six three inches high by six point seven five inches long and six point seven five inches wide
- Constructed with Schedule 40 PVC material
Product Highlights
Ideal for cold water pressure distribution systems, including applications in irrigation, pools, and chilled water systems.
Product Information
Standard Information
-
Brand: NIBCO
-
Model Number: 409-005
Technical Specifications
-
Material: PVC
-
Dimensions: 1/2 inch
-
Maximum Temperature: +140 degrees Fahrenheit
-
Catalog Number: 409-005
-
Specifications Met: ASTM D1784/D2466, NSF/ANSI 61
-
Application: Irrigation, pool and spa, potable water, chilled water
-
Resistance Properties: Chemical-resistant, corrosion-resistant
-
Weight: 0.06 pounds
