Nibco 39923767622 Gd-4775-5 2 inches Grooved Ductile Iron Butterfly Valve NLK720D

Product Description

The NIBCO 39923767622 Gd-4775-5 is a 2" grooved ductile iron butterfly valve featuring an EPDM encapsulated ductile iron disc and a stainless steel stem with metal bushings. It includes a splined drive, extended neck, and gear-operated handle. Designed to meet MSS SP-67 and MSS SP-25 (markings). Not recommended for steam service.

• Valve pressure rating 300 psi (2" to 10"); 200 psi (12" only)
• Maximum temperature rating 180°F
• Stainless steel stem with metal bushings

Product Highlights

This 2" grooved butterfly valve is constructed from ductile iron and features a gear-operated handle, ideal for various industrial applications.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: 39923767622
• Country of Origin: US

Technical Specifications

• Manufacturer: NIBCO
• Part Number: NLK720D
• Model: GD-4775-5
• Valve Type: Butterfly Valve
• Connection: 2" Grooved
• Material: Ductile Iron
• Maximum Pressure: 300 psi
• Maximum Temperature: 180°F
• Handle Style: Gear-Operated
• Stem Material: Stainless Steel
• Turns Operations: Quarter-Turn
• Length: 11.64"
• Width: 9"
• Height: 6.93"
• Disc Material: EPDM Encapsulated Ductile Iron
