Nibco 39923675262 Ball Valve (1 1/2 in)

Product Description

Nibco 39923675262 is a 1 1/2-inch ball valve with quarter-turn (90 degree) operation designed for commercial and light industrial process applications. The valve has a cast red bronze two-piece body, female solder cup connections, reinforced RPTFE seals and a blowout-proof stem. It is rated to 600 psi cold working pressure and 400 F maximum fluid temperature and conforms to MSS SP-110 for HVAC, domestic water and low-pressure steam service.

• Quarter-turn (90 degree) operation with blowout-proof stem and standard lever handle; top-of-handle to inlet center 3 in
• Rated 600 psi maximum fluid pressure and 400 F maximum fluid temperature; maximum steam pressure 150 psi
• Cast red bronze two-piece body, female solder cup connection, reinforced RPTFE seal, silicon bronze stem; made in USA

Product Highlights

1-1/2 in cast red bronze ball valve; 600 psi, 400 F rating; female solder cup; conforms to MSS SP-110

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: 39923675262
• Country of Origin: USA

Technical Specifications

• Brand: Nibco
• Manufacturer Part Number: 39923675262
• Mfr Model: S-580-70
• Product UID: 580S-112
• Product Type: Ball Valve
• Pipe Size: 1 1/2 in
• Body Material: Cast red bronze
• Connection Type: Female solder cup
• Handle Material: Zinc plated steel clear chromate plastisol coated
• Stem Material: Silicon bronze
• Seal Material: RPTFE (Reinforced)
• Valve Stem: Blowout-proof stem
• Top Of Handle To Inlet Center: 3 in
• Max Fluid Pressure: 600 psi
• Max Fluid Temperature: 400 F
• Max Steam Pressure: 150 psi
• Media: Conventional port
• Shape: Two-piece body
• Standards: Conforms to MSS SP-110
• Made In USA: Yes
