NIBCO 2024950HPC 3/4-Inch BenchPressG Carbon Steel Press X Female Adapter

Product Description

The NIBCO 2024950HPC is a three-fourths inch BenchPressG carbon steel press x female adapter. This adapter features a press connection on one end and a female NPT thread on the other. It is ideal for connecting press systems to threaded connections.

• Includes a yellow HNBR O-ring for secure sealing.
• Equipped with a stainless steel gripper ring for enhanced performance.
• Designed specifically for gas applications.

Product Highlights

This adapter is built to create a dependable seal when pressure is applied using a pressing tool.

Product Information

Standard Information

• Manufacturer: NIBCO
• Item Name: Adapter

Technical Specifications

• MPN: 2024950HPC
• Model: PCH203
• Connection Type: Press x FPT
• Material: Carbon Steel
• Maximum Pressure: 200 PSI
• Temperature Rating: -20 to 250 degrees F
• Nominal Size: 3/4 inch
• Length: 1.97 inches
• Width: 1.5 inches
• Height: 1.5 inches
• Country of Origin: CN
