Niagara Cutter NIAGA-03011284 N71487 Series End Mill Corner Chamfer Extended Reach

Product Description

Niagara Cutter N71487 Series End Mill is designed for cutting in various materials, including high-temperature alloys. This end mill features a corner chamfer and an extended reach for versatile applications. It incorporates six flutes for efficient material removal and has a single end square design with a non-center cutting edge.

• Cutter diameter measures one and a half inches.
• Overall length is four and a half inches with a shank diameter of one and a quarter inches.
• Constructed from cobalt material, uncoated for durability.

Product Highlights

This end mill caters to a variety of milling applications, making it suitable for both professionals and tradespeople in metalworking.

Product Information

Standard Information

• Brand: Niagara Cutter
• MPN: NIAGA-03011284

Technical Specifications

• ANSI Code: REM710-1.500-P5-C040.3-Z6
• Cutting Direction: Right Hand
• Flute Type: Coarse Pitch, Spiral
• Helix Angle: 30 degrees
• ISO Code: REM7101.500P5C040.3Z6
• Material: Cobalt
• Series: N71487
• Shank Length: 2.5 inches
• Shank Type: Weldon Flat
• Type: Corner Chamfer, Extended Reach, Non-Center Cutting, Single End, Square End
• Cutter Diameter: 1.5 inches
• Corner Radius: 0.125 inches
• Number of Flutes: 6
• Shank Diameter: 1.25 inches
• Overall Length: 4.5 inches
• Finish: Uncoated
