Neutrik Americas NBNC75BTU11 Bnc Connector 75 Ohm

Product Description

The NEUTRIK AMERICAS NBNC75BTU11 is a BNC die connector designed for 75 ohm coaxial cable terminations with a 1.6mm cable diameter. This is a crimp or compression die insert used with compatible BNC tooling to terminate coaxial cable in audio, video, and low-voltage signal distribution systems. It is sold as a single unit and is suited for use by low-voltage technicians, AV installers, and electricians working with coaxial signal wiring in residential, commercial, or broadcast environments. The 75 ohm impedance rating matches standard video and RF signal cable specifications.

This die insert is intended for use in professional cable termination tooling to produce reliable BNC connector terminations on 1.6mm diameter 75 ohm coaxial cable. Typical applications include structured cabling, broadcast video runs, CCTV, and other signal distribution installations where consistent and repeatable BNC terminations are required. It is commonly used by AV integrators and low-voltage installers on commercial and residential projects.

Key Features

• 75 ohm impedance rating matches standard video and RF coaxial cable
• Designed for 1.6mm cable diameter terminations
• Compatible with BNC connector tooling systems for repeatable crimps
• Sold individually as a single unit replacement or addition to tooling sets
• Suited for structured cabling, CCTV, broadcast video, and RF signal applications

Compatibility

Designed as a die insert for BNC connector tooling systems compatible with 75 ohm coaxial cable at 1.6mm cable diameter. Consult NEUTRIK AMERICAS tooling documentation to confirm die-to-tool compatibility before use.

Installation Notes

Installation is performed by low-voltage technicians or AV installers using compatible BNC termination tooling. Verify that the die size and impedance match both the cable and the connector before terminating. Follow the tool manufacturer instructions for proper die seating and crimp force. Reference applicable low-voltage wiring codes and project specifications for signal cable handling requirements.
