NEUCO MS7505A2030 Spring Return Direct Coupled Actuator

Product Description

The NEUCO MS7505A2030 is a spring return direct coupled actuator. It operates on twenty-four volts alternating current or direct current power and accepts two to ten volts direct current and four to twenty milliamperes control signals with a five hundred-ohm resistor. This actuator provides on/off, single pole double throw, and floating control signal capabilities, along with two to ten volts direct current feedback. It features a ninety-second nominal driving time and a maximum spring return time of twenty-five seconds. The device offers forty-four pound-inches of torque and a rotational stroke of ninety-five degrees plus or minus three degrees.

• Spring return functionality
• Accepts multiple control signal types
• Enclosed screw terminal strip for electrical connections

Product Highlights

The actuator is designed for efficient control in HVAC systems, providing reliable operation with various input signals.

Product Information

Standard Information

• Brand: NEUCO
• MPN: MS7505A2030

Technical Specifications

• Input Voltage: 24Vac/Dc
• Control Signal: 2-10Vdc, 4-20Ma with 500 Ohm Resistor
• Feedback Signal: 2-10 Vdc
• Driving Time: 90 Second Nominal
• Spring Return Time: 25 Second Maximum
• Torque: 44 Lb-In
• Rotational Stroke: 95 ± 3 Degrees
• Electrical Connections: Enclosed Screw Terminal Strip
• Enclosure Rating: Nema 2
• Humidity Range: 5-95% RH
• Weight: 3.7LB
• Dimensions: 10.3x5x4.35
