Product Description
The Netafim TL050MFV-1 automatic flush valve is engineered for reliable, low-maintenance flushing of Techline drip systems. Designed to remove sediment and debris at the start of each irrigation cycle, this flow-activated valve helps prevent clogging and preserves dripline performance with minimal water loss.
- Automatically flushes sediment and debris at system start-up to reduce clogging and maintain consistent dripline performance.
- Eliminates the need for manual flushing, saving maintenance time and effort.
- Flow-activated design operates reliably even at full line pressure for dependable cleaning cycles.
Product Highlights
This automatic flush valve helps reduce maintenance to your irrigation system and increase dripline performance. It ensures optimum system operation and performance.
Product Information
Standard Information
-
Brand: NETAFIM
-
Manufacturer Part Number: TL050MFV-1
-
Country of Origin: US
Technical Specifications
-
Flush volume: Approximately 1 gallon per cycle — effective, low-waste flushing
-
Maximum zone flow per flush: 15 GPM to ensure proper cleaning for typical residential and commercial zones
-
Inlet connection: 1/2" MPT (nominal 1/2 in) for direct connection to supply fittings
-
Operating pressure range: Minimum 1.5 PSI; maximum 57 PSI for consistent operation across common systems
-
Flow-activated design: Operates by flow rather than pressure so it reliably flushes at line start-up
-
Serviceability: Disassembles for winterization and easy maintenance; compatible with Techline 17 mm dripline connections
-
Construction & finish: Durable brown plastic body sized for standard dripline installations; sold individually
-
Item: Valve
-
Type: Automatic Flush
-
Connection Size: 1/2 in.
-
Connection Type: Mipt
-
Color: Brown
-
Flow Rate: 1 GPH
-
Regulated: No
-
Brand Name: Netafim
-
Exterior Finish: Stainless Steel
-
Inlet Connection Type: Threaded
-
Number of Ports: 2
-
Valve Type: check valve
-
Inlet Connection Size: 1 Inches
-
Material Type: Metal
-
MPN: TL050MFV-1
-
Material: Plastic
-
Item Length: 7
-
Item Width: 7
-
Item Height: 7
-
Compatible Brand: Netafim
-
Model: TL050MFV-1
-
Compatible Model: TL050MFV-1
-
Manufacturer Part Number: TL050MFV-1
-
SPECIAL_ORDER_ITEM: N
-
Special Order Item: N
