Nds 9253 Class A Plastic Square Deco 2 inches x 36 inches Grate

Product Description

The NDS 9253 slim channel grate is a professional-grade drainage solution perfect for both contractors and homeowners. Measuring 3 feet in length, this grate features a square design pattern that ensures excellent flow capacity to efficiently manage water in outdoor living areas. Its durable polypropylene construction ensures longevity.

• ADA Compliant
• Heel-Proof
• Snap-in grate
• Easy installation and replacement
• Suitable for residential outdoor living areas
• Fits NDS Slim Channel grates
• Light-duty load capacity
• Perfect for low-traffic applications

Product Highlights

The NDS 9253 slim channel grate is ideal for pools, spas, and patios.

Product Information

Standard Information

• Brand: NDS
• Manufacturer Part Number: 9253

Technical Specifications

• Grate Width: 2.25" for NDS Slim Channel
• Grate Height: 0.25" with T-Top
• Grate Material / Color / Finish: Plastic/HDPE - Gray
• Manufacturer: NDS
• System: Slim Channel
• Grate Load Class: Class A
• Grate Pattern: Square Deco
• Application: Residential
• Use With: NDS Slim Channel Drain (#9206)
• Flow Capacity: 17.53 GPM / linear foot
• ADA Compliant: Yes
• Load Recommendation: Class A (00-65 PSI / 3,372 lbs per foot)
• Material: UV Protected High-Density Polyethylene (HDPE)
• Part Number: 9253
• Length: 3 ft
• Width: 2-1/4 in
• Grate Opening: .246"
• Open Surface Area: 7.09 sq. in / linear foot
• Gallons Per Minute: 21.69 GPM / linear foot
• Additional Information: Decorative-Style
• Flow Rate: 21.44 gpm
• Height: 0.42 in
• Shape: Square
• Special Order Item: N
• Suitable For Use With: 1-1/2 in SCH 40 Pipes
• Surface Area: 5.73 sq-in
