Nds 900 Double Outlet Catch Basin 9x9 Inches

Product Description

The NDS 900 is a 9 inch by 9 inch double outlet catch basin designed for surface water collection and drainage management. It accepts two separate outlet connections, making it suitable for installations where flow must be directed to multiple discharge points or where higher drainage capacity is needed. This basin is a core component in subsurface drainage systems commonly installed by plumbers, landscape drainage contractors, and site utility tradespeople. Each unit weighs 10 pounds and ships in a package quantity of four.

The NDS 900 is used in residential and light commercial drainage applications including yard drainage, driveway runoff collection, and parking area water management. Its double outlet configuration supports flexible piping layouts. Each outlet opening requires a compatible universal outlet fitting — specifically the 1206, 1242, 1243, 1245, 1266, or 1889 universal outlet — to complete the assembly. These outlet fittings are sold separately and must be selected based on the pipe size and connection type used on the project.

Key Features

• Double outlet design allows two independent drainage discharge connections
• 9 inch by 9 inch basin footprint suits standard residential and light commercial drainage layouts
• Compatible with multiple NDS universal outlet fittings for flexible pipe connection options
• Sold in a package quantity of four units
• Lightweight construction at 10 pounds per unit for ease of handling during installation

Compatibility

Each outlet opening requires one of the following NDS universal outlet fittings: 1206, 1242, 1243, 1245, 1266, or 1889. Two outlet fittings are required per basin. Outlet fittings are not included.

Installation Notes

Installation is typically performed by licensed plumbers or drainage contractors following applicable local plumbing and grading codes. Excavate to the required depth and ensure proper slope toward the basin inlet before setting the unit. Power tools are not required for basin placement, but pipe cutters and solvent weld materials may be needed depending on the outlet fitting and pipe type selected. Always verify local code requirements for drainage system depth, outlet pipe sizing, and surface grate load ratings before completing the installation.

Technical Specifications

• Basin Size: 9 inches x 9 inches
• Outlet Configuration: Double outlet
• Weight: 10 pounds
• Package Quantity: 4 units per package
• Unit of Measure: EA

Standard Information

• Brand: NDS
• Manufacturer Part Number: 900
