Nds 1011-20 2 inches pvc s by s 7 inches length spring check valve

Product Description

The NDS 1011-20 2" PVC S by S 7" Length Spring Check Valve prevents backflow and keeps prime in water systems. The 1/2 lb spring gives a positive seal with no back pressure. It complies with all applicable ASTM & ANSI standards. Designed for systems where back flow is not desired, such as spas, swimming pools, industrial and irrigation.

• High-Impact PVC type II material for use in hot or cold fluid systems up to 140 Deg. F
• Connections: 2-inch slip by 2-inch slip
• 150 psi working pressure at 73 Deg. F

Product Highlights

This NDS spring check valve is made of PVC and has a 2-inch slip connection. It has a 1/2 lb spring and complies with ASTM & ANSI standards.

Product Information

Standard Information

• Brand: NDS
• Manufacturer Part Number: 1011-20
• Country of Origin: USA

Technical Specifications

• Material: PVC
• Valve Type: Spring check
• Exterior Finish: Pvc
• Size: 2" x 2"
• Approvals: NSF61, NSF372
• Connection Type: Slip Joint
• Pressure Rating: 200 psi
• Connection Method: Socket
• Open Pressure (PSI): 0.88
• Length: 7 in
• Softgoods Material: EPDM Rubber
• Temperature Rating: 72 deg F
• Trim Material: Stainless Steel
• Width: 4-1/32 in
• Nominal Size: 2 in
• Body Material: PVC
• Series: 1011 Series
• Includes: 1/2# Spring
