NACHI 22210EXW33C3 NAC Spherical Roller Bearing 50 mm Bore 90 mm OD 22210 EXW33C3 NAC

Product Description

The NACHI 22210EXW33C3 is a spherical roller bearing designed for high axial and heavy load applications. It features a cylindrical bore with a diameter of fifty millimeters and an outside diameter of ninety millimeters. The double-row design provides excellent performance under various conditions.

• High load capacity: 142000 N dynamic/122000 N static.
• Designed for use in extreme radial load applications.
• Open closure type allows for easy lubrication access.

Product Highlights

This bearing is suitable for gearboxes, wind turbines, and heavy machinery.

Product Information

Standard Information

• Brand: NACHI
• Manufacturer: Nachi Bearings

Technical Specifications

• Series: 22200
• Bore Diameter: 50 mm
• Outside Diameter: 90 mm
• Width: 23 mm
• Load Capacity: 142000 N dynamic/122000 N static
• Maximum Speed: 5600 rpm Grease/7100 rpm Oil
• Temperature Rating: 400 deg F
• Cage Material: Pressed Steel
• Number of Rows: 2
• Bearing Material: Steel Alloy
