Multi Fittings 078623 PVC 90-Degree Elbow Sch 80 1-1/4 in

Product Description

Multi Fittings 078623 is a schedule 80 PVC 90-degree conduit elbow for 1-1/4 in trade size conduit. It provides a 90-degree directional change with a 7-1/4 in bend radius, 16-1/2 in overall length and a 2-1/2 in thread length, and uses plain solvent-weld ends. Manufactured from impact-resistant rigid PVC, the fitting is suitable for exposed, concrete-encased, and direct burial conduit installations and meets conduit standards.

• Schedule 80 impact-resistant PVC construction for conduit systems
• 1-1/4 in trade size, 90-degree elbow with 7-1/4 in bend radius and 16-1/2 in overall length
• Plain solvent-weld connection; suitable for exposed, concrete-encased, and direct burial installations; meets UL 651 conduit standard

Product Highlights

Schedule 80 PVC 90-degree elbow, 1-1/4 in trade size, plain solvent-weld ends, 7-1/4 in bend radius

Product Information

Standard Information

• Brand: MULTI FITTINGS
• Manufacturer Part Number: 078623
• Country of Origin: Canada

Technical Specifications

• Manufacturer: Multi Fittings Corp
• Brand: Multi Fittings
• Part Number: 078623
• Type: Standard elbow
• Material: PVC (schedule 80, rigid, impact-resistant)
• Angle: 90 deg
• Trade Size: 1-1/4 in
• Connection Type: Plain (for non-metallic solvent weld fittings)
• Connection (alternate listing): SPxSP (socket x socket)
• Bend Radius: 7-1/4 in
• Overall Length: 16-1/2 in
• Thread Length: 2-1/2 in
• Suitable For Use With: Non-metallic solvent weld fittings
• Standard: UL 651
• Electrical Category: Conduit and Fittings
• Electrical Subcategory: Conduit Fittings
• Country Of Origin: Canada
• RoHS Compliance: No
• UNSPSC: 39131717
• UPC: 00622454786233
• Spec Sheet: http://pim.itinfonet.com/web/idw/SpecificationSheets/078623-03_CPD.pdf
