MULTI FITTINGS 019216 Inline Tap Connector and Quick Release Fitting

Product Description

The Multi Fittings 019216 comprises an inline tap connector and a quick release fitting. The inline tap connector is designed for terminating 10 to 12 AWG wires. It has a hinged lid and is fully insulated. The quick release fitting has a 90-degree bend and a one-inch thread, suitable for tubes with a thirty-four point five millimeter outer diameter. It features a rotatable brass male thread and is made from polyamide with TPE sealing.

• Inline tap connector designed for 10 to 12 AWG wires.
• Quick release fitting with a 90-degree bend and one-inch thread.
• Compatible with tube outer diameter of thirty-four point five millimeters.

Product Highlights

This product is essential for various wiring applications, providing secure connectivity and easy installation.

Product Information

Standard Information

• Manufacturer: Molex
• Lead Free Status: RoHS Compliant

Technical Specifications

• Wire Gauge: 10-12 AWG
• Termination: IDC
• Terminal Type: Inline, Tap
• Number of Wire Entries: 2
• Moisture Sensitivity Level: 1
• Insulation: Fully Insulated
• Thread: 1 inch
• Thread Length: 18.0 mm
• Tube Outer Diameter: 34.5 mm
• Inner Diameter: 24.5 mm
• Height: 100.0 mm
• Width Across Flats: SW43
• Temperature Range: -40°C to 120°C
• Protection Class: IP68 / IP69K
• Material: Polyamide, TPE, Brass
• Color: Yellow
