Mueller Valve A-2600-6-01 Swing Type Lever and Weight Check Valve 2 inches-12 inches

Product Description

The MUELLER VALVE A-2600-6-01 is a swing type lever and weight check valve available in sizes 2"-12". It meets ANSI/AWWA C508 standards and features an epoxy-coated interior and exterior for corrosion resistance. Certified to NSF/ANSI/CAN 61, it has flanged end dimensions complying with ANSI B16.1, class 125. The valve has an iron body, bronze mounting (IBBM).

• Choice of bronze or rubber disc facing
• For vertical or horizontal installation
• O-ring sealed stuffing box

Product Highlights

Adjustable weight controls clapper opening/closing. Lever can be installed on either side. Maximum working pressure: 200 psig. Test pressure: 400 psig.

Product Information

Standard Information

• Brand: MUELLER VALVE
• Manufacturer Part Number: A-2600-6-01

Technical Specifications

• Sizes: 2", 2-1/2", 3", 4", 6", 8", 10", 12"
• Standard: Meets all applicable parts of ANSI/AWWA C508 Standard
• Coating: Epoxy coated interior & exterior for corrosion resistance
• Certification: Certified to NSF/ANSI/CAN 61
• Flanged End Dimensions: Comply with ANSI B16.1, class 125
• Body: Iron body, bronze mounted (IBBM)
• Disc Facing: Choice of bronze or rubber disc facing
• Installation: For vertical or horizontal installation
• Stuffing Box: O-ring sealed stuffing box
• Maximum Working Pressure: 200 psig (1400 kPa/14 barg)
• Test Pressure: 400 psig (2800 kPa/28 barg)
