Mueller Streamline TEE00033 Copper Solder Tee 1/4in

Product Description

The MUELLER STREAMLINE TEE00033 is a wrot copper solder tee fitting designed for joining copper tubing in plumbing, refrigeration, and HVAC systems. With a 1/4 x 1/4 x 1/4 inch connection configuration and a 90-degree branch angle, this fitting allows a clean three-way split in a copper line set or fluid circuit. Wrot copper construction means it is formed from wrought copper stock, delivering consistent wall thickness and reliable sweat joints. The fitting meets NSF, UL, and UR standards and is rated for service from -20 to 400 degrees F, covering the full range of residential and light-commercial plumbing and refrigeration applications.

This tee is suited for small-diameter copper tubing work in refrigeration line sets, ACR piping, potable water distribution at reduced pipe sizes, and other applications requiring a 1/4 inch solder connection. Plumbers and HVAC-R technicians install this fitting using standard soldering or brazing procedures. Its compact actual dimensions of 1.06 inches in length, 0.42 inches in width, and 0.74 inches in height make it appropriate for tight-clearance installations inside equipment cabinets or wall cavities.

Key Features

• Wrot copper construction for consistent wall thickness and strong, leak-free sweat joints
• 1/4 x 1/4 x 1/4 inch solder-end connections with 90-degree branch angle
• Rated -20 to 400 degrees F, suitable for refrigeration and plumbing service
• NSF, UL, and UR standards compliance
• Compact profile: 1.06 inches long, 0.42 inches wide, 0.74 inches tall
• Lightweight at 0.06 pounds actual weight

Compatibility

Designed as an OEM-style solder fitting for 1/4 inch outside-diameter copper tubing used in residential and light-commercial plumbing, refrigeration, and HVAC-R piping systems.

Installation Notes

Installation is performed by licensed plumbers or HVAC-R technicians using standard copper soldering or silver-brazing procedures. Shut off and depressurize the system completely and drain all fluid from the line before cutting in the fitting. Clean all mating tube ends and fitting sockets with emery cloth and apply appropriate flux before soldering. Work must comply with applicable local plumbing codes and ASHRAE standards for refrigerant piping where required.

Technical Specifications

• Connection Size: 1/4 x 1/4 x 1/4 inches
• Connection Type: Copper Solder
• Angle: 90 degrees
• Temperature Rating: -20 to 400 degrees F
• Actual Length/Depth: 1.06 inches
• Actual Width: 0.42 inches
• Actual Height: 0.74 inches
• Actual Weight: 0.06 pounds
• Standards Compliance: NSF, UL, UR

Standard Information

• Brand: MUELLER STREAMLINE
• Manufacturer Part Number: TEE00033
