Mueller Streamline ELL00895 Wrot Copper 45 Deg Elbow

Product Description

The MUELLER STREAMLINE ELL00895 is a 45-degree wrot copper solder elbow designed for permanent sweat-joint connections in copper tubing systems. With a 1/2 inch by 1/2 inch C x C configuration, this fitting accepts standard copper tubing on both ends and is soldered in place using a torch and appropriate flux and solder. Wrot copper construction provides high tensile strength and reliable leak resistance across a wide range of operating pressures and temperatures. At 0.04 pounds, the fitting is compact and lightweight, with actual dimensions of 1.52 inches in length, 1.19 inches in height, and 0.69 inches in width. Plumbers and pipefitters install this elbow wherever a 45-degree directional change is required in a copper water or hydronic system.

This fitting is suited for residential and light commercial plumbing, hydronic heating, and refrigeration piping applications where copper sweat connections are specified. The 45-degree angle allows for gradual directional changes with lower flow resistance compared to a 90-degree elbow, making it a common choice in supply lines, branch runs, and tight-space routing. Installation follows standard sweat-soldering practice per IPC and IFGC guidelines where applicable.

Key Features

• 45-degree angle provides a gradual directional change in copper piping runs
• Wrot copper construction delivers high strength and long-term corrosion resistance
• C x C solder connection on both ends for standard sweat-joint installation
• 1/2 inch by 1/2 inch connection size fits common residential and commercial copper tubing
• Compact profile at 1.52 inches in length supports use in confined spaces

Compatibility

Designed as an OEM-style replacement and standard-use fitting compatible with 1/2 inch nominal copper tubing in sweat-joint plumbing and hydronic piping systems.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter following local plumbing codes. Shut off and drain the water supply before cutting into an existing system. Clean and flux all mating surfaces before applying heat and solder. Avoid overheating the fitting during soldering, as excessive heat can compromise joint integrity.

Technical Specifications

• Material: Wrot Copper
• Connection Type: C x C (Solder)
• Connection Size: 1/2 x 1/2 inch
• Angle: 45 degrees
• Actual Length/Depth: 1.52 inches
• Actual Height: 1.19 inches
• Actual Width: 0.69 inches
• Actual Weight: 0.04 pounds

Standard Information

• Brand: MUELLER STREAMLINE
• Manufacturer Part Number: ELL00895
