Mueller Streamline ELL00207 Copper 90 Degree Street Elbow

Product Description

The MUELLER STREAMLINE ELL00207 is a wrot copper 90-degree street elbow designed for sweat-connection plumbing assemblies. With a fitting-by-copper (FTG x C) connection type, it accepts a 2-inch fitting on the male end and a 2-inch copper tube on the female end, eliminating the need for an additional coupling at that joint. The long-radius design reduces turbulence and pressure drop through the turn. It measures 5.43 inches in length and 5.28 inches in height, with an actual weight of 1.23 pounds. This fitting is specified by licensed plumbers for both new construction and retrofit work in copper piping systems.

This elbow is suited for residential and light commercial plumbing installations where a 90-degree directional change is required in a 2-inch copper line. The street configuration is commonly used when connecting directly to a valve, fitting outlet, or fixture port without an intermediate section of tubing. It is installed in supply, recirculation, and hydronic distribution systems.

Key Features

• 90-degree long-radius street elbow minimizes flow restriction through the bend
• FTG x C connection allows direct male-to-socket sweat joining
• Wrot copper construction provides durability and compatibility with standard lead-free solder
• 2 x 2 inch connection size suits common residential and commercial line sizes
• Compact form factor at 2.25 inches wide fits standard joist and stud bay installations

Compatibility

Designed as an OEM-style replacement and new-installation fitting for 2-inch copper plumbing systems using sweat (solder) connections per standard copper fitting dimensions.

Installation Notes

Installation is performed by a licensed plumber following applicable IPC or local plumbing code requirements. Shut off and drain the water supply before cutting into any existing line. Clean and flux all mating surfaces before applying heat; use lead-free solder where required by code. Avoid overheating the fitting, as excessive heat can damage adjacent components or compromise the joint.

Technical Specifications

• Material: Wrot Copper
• Angle: 90 degrees
• Adapter Type: Long Radius, Street
• Connection Type: FTG x C
• Connection Size: 2 x 2 inches
• Actual Height: 5.28 inches
• Actual Length/Depth: 5.43 inches
• Actual Width: 2.25 inches
• Actual Weight: 1.23 pounds

Standard Information

• Brand: MUELLER STREAMLINE
• Manufacturer Part Number: ELL00207
