Mueller Streamline A11212NL Union 1 inches Cxm

Product Description

The MUELLER STREAMLINE A11212NL is a union fitting with a straight type. It features a size A of 1 inch and a size B of 1 inch. Constructed from brass alloy with a cast process, it is designed for non-pressurized DWV sanitary systems. The end connection is female soldered x male threaded and conforms to ASME B16.23/29 and NSF 61G standards.

• Lead-Free
• End Connection: Female Soldered x Male Threaded
• Application: Non-Pressurized DWV Sanitary System

Product Highlights

This lead-free union fitting is ideal for non-pressurized DWV sanitary systems, offering a reliable connection with its female soldered x male threaded ends.

Product Information

Standard Information

• Brand: MUELLER STREAMLINE
• Manufacturer Part Number: A11212NL
• Country of Origin: United States

Technical Specifications

• Applicable Standard: ASME B16.23/29, NSF 61G
• Application: Non-Pressurized DWV Sanitary System
• Catalog Number: A11212NL
• End Connection: Female Soldered x Male Threaded
• Material: Brass Alloy
• Process: Cast
• Size A: 1 Inch
• Size B: 1 Inch
• Type: Straight
• Outer Diameter: 1-1/8 Inch
• Brand: MUELLER STREAMLINE
• Operating Temperature: N/A
• Operating Pressure: N/A
• End Type: C - Cup (Female Solder)
• End Size: 1
• Second End Type: MPT - Male Pipe Tapered Thread (NPT)
• Second End Size: 1
• Standards: ASME B16.15, ASME B16.18, ASME B16.22, ASME B16.24, ASME B16.50, ASME B1.20.1
• Overall Length: 3.00 in
• Overall Height: 2.10 in
• Overall Width: 2.10 in
• Style: C-108
• Mueller Description 1: 1 C X M UNION
• Mueller Description 2: 1-1/8 OD X 1M UNION
• Country of Origin: United States
• Condition: New
