Mueller Streamline A 18959 Cyclemaster Ball Valves 1/4 in FTG x FTG

Product Description

The MUELLER STREAMLINE A 18959 CYCLEMASTER Ball Valves feature FTG x FTG ends. Designed for use with Streamline ACR Copper Press Fittings, these valves are UL Recognized to 700 PSI and compatible with R410A and other commonly used refrigerant gases and oils. They allow for turnkey installation into flameless HVACR systems.

• Designed with FTG x FTG ends for easy use with Streamline ACR Copper Press Fittings
• UL Recognized to 700 PSI
• Compatible with R410A and other commonly used refrigerant gases and oils

Product Highlights

CYCLEMASTER Ball Valves with FTG x FTG ends for HVACR systems, UL Recognized, and compatible with various refrigerant gases.

Product Information

Standard Information

• Brand: MUELLER STREAMLINE
• Manufacturer Part Number: A 18959

Technical Specifications

• Connection Size: 1/4 in
• End Type: FTG
• Cv: 1.00
• Kv: 1
• MAP: 775 psi
• Operating Temperature [Min]: -40 °F
• Operating Temperature [Max]: 300 °F
• A: 6.51 in
• B: 3.62 in
• C: 2.52 in
• D: 2.23 in
• E: 1.69 in
• F: 0.25 in
• G Min: 0.38 in
• H: 1.16 in
• Overall Length (In.): 6.51
