Mueller Streamline 107-403NL Ball Valve (1/2 Inch)

Product Description

The Mueller Streamline 107-403NL is a ball valve with female iron pipe (FIP) threaded connections and a 1/2 inch nominal size. It features brass construction with a chrome exterior, a full-port ball design and quarter-turn operation. The valve is rated to 600 IPS pressure and up to 300 F, includes a Dacromet-plated handle, and is specified for use with flammable liquid applications.

• 600 IPS pressure rating and maximum temperature 300 F
• 1/2 inch FIP (female iron pipe) threaded connections; full-port ball design; quarter-turn operation
• Brass construction with chrome finish, Dacromet-plated handle, lead-free

Product Highlights

1/2 inch full-port brass ball valve with FIP threads, 600 IPS rating, quarter-turn Dacromet handle

Product Information

Standard Information

• Brand: MUELLER STREAMLINE
• Manufacturer Part Number: 107-403NL
• Country of Origin: Italy

Technical Specifications

• Brand: MUELLER STREAMLINE
• Manufacturer Part Number: 107-403NL
• Product Type: Ball valve
• Valve Type: Full-port ball valve
• Connection Type: FIP (female iron pipe) threaded
• Connection Size: 1/2 inch
• Size: 1/2 inch
• Maximum Pressure: 600 PSI
• Maximum Temperature: 300 F
• Material: Brass
• Exterior Finish: Chrome
• Handle: Dacromet-plated
• Operation: Quarter-turn
• Lead Content: Lead-free
• Threaded: Yes
• Country Of Origin: Italy
• Weight: 0.43 lb (0.1935 kg)
• Item Code: EC4VDN
• UPC: 032888110328
• Application: For use with flammable liquid
