Mueller Industries RP01011 DuoSeal 3/8 x 1/4 O.D. Copper Press Refrigeration Coupling (5 Pack)

Product Description

Mueller Industries RP01011 is a DuoSeal press reducing coupling that joins 3/8-inch to 1/4-inch outside diameter copper tubing for air conditioning and refrigeration applications. The fitting uses a press connection and is supplied as a pack of five. It is approved for use with Type ACR, L, and K hard and soft copper tube and is compatible with common refrigerants including R410A.

• DuoSeal/press design for refrigeration and ACR tubing; connects 3/8 in OD to 1/4 in OD copper
• Two Ring Advanced Press (T.R.A.P.), DualSeal ring, TrapZone leak barrier, Force360 contour, and Tri-Lock profile for enhanced sealing and joint strength
• Rated to 700 psi operating pressure and -40 to 250 deg F operating temperature; overall length approximately 2.24 in

Product Highlights

Press reducing coupling for 3/8 x 1/4 OD copper tubing, pack of 5, compatible with ACR/L/K tube and refrigerants including R410A

Product Information

Standard Information

• Brand: MUELLER INDUSTRIES
• Manufacturer Part Number: RP01011
• Country of Origin: United States

Technical Specifications

• Brand: MUELLER INDUSTRIES
• MPN: RP01011
• Product Type: Press reducing coupling
• Material: Copper
• Connection Type: ACR press
• Nominal Size: 3/8 x 1/4 in
• End Size (Primary): 3/8 in OD
• End Size (Secondary): 1/4 in OD
• Approved Tube Types: Type ACR, L, K hard and soft copper tube
• Operating Temperature: -40 to 250 deg F
• Operating Pressure: 700 psi
• Overall Length: 2.24 in
• Weight: 0.06 lb
• Quantity per Bag: 5
• Compatible Refrigerants: R410A and other common refrigerants and oils
• Features: Two Ring Advanced Press (T.R.A.P.), DualSeal ring design, TrapZone leak barrier, Force360 press contour, Tri-Lock press profile
