Mueller Industries CP03055 45 Deg Press Elbow 1-1/2 in

Product Description

The MUELLER INDUSTRIES CP03055 is a 45-degree elbow fitting manufactured from carbon steel, designed for use in press-connect piping systems. It accepts 1-1/2 inch press connections on both ends, allowing directional changes in hydronic, radiant, or mechanical piping runs without soldering or threading. Rated to 200 psi and suitable for operating temperatures from -40 degrees F to 250 degrees F, this fitting is built for demanding commercial and residential mechanical applications. Licensed plumbers and pipefitters install this type of fitting using a press tool with the appropriate jaw set for carbon steel press fittings.

This elbow is suited for hydronic heating systems, chilled water distribution, and general mechanical piping where press-connect carbon steel fittings are specified. The 45-degree angle makes it the preferred choice when routing pipe around obstructions or transitioning pipe direction at a shallower offset than a standard 90-degree elbow. It is commonly used in boiler rooms, mechanical rooms, and in-wall or under-slab installations where flame-free joining methods are required or preferred by code or contractor preference.

Key Features

• Press x press end connections on both ends — no soldering, threading, or open flame required
• 1-1/2 inch end size on both sides for consistent pipe sizing throughout the run
• Rated to 200 psi operating pressure for use in pressurized piping systems
• Wide temperature range from -40 degrees F to 250 degrees F supports heating and cooling applications
• Carbon steel construction provides durability in mechanical and industrial piping environments

Compatibility

Designed as an OEM-style press fitting for carbon steel press-connect piping systems with 1-1/2 inch pipe connections. Verify press tool jaw compatibility with carbon steel press fittings before installation.

Installation Notes

Installation must be performed by a licensed plumber or pipefitter using a calibrated press tool fitted with jaws rated for carbon steel press connections. Depressurize and drain the piping system before removing or installing any fittings. Inspect the pipe end for burrs, debris, and proper insertion depth markings before pressing. Follow all applicable local plumbing codes and manufacturer pressing tool guidelines to ensure a leak-free joint.

Technical Specifications

• Material: Carbon Steel
• End Type: Press
• Second End Type: Press
• End Size: 1-1/2 inches
• Second End Size: 1-1/2 inches
• Operating Pressure (Max): 200 psi
• Operating Temperature (Min): -40 degrees F
• Operating Temperature (Max): 250 degrees F
• Weight: 1.03 pounds

Standard Information

• Brand: MUELLER INDUSTRIES
• Manufacturer Part Number: CP03055
