Mueller Industries CP02072 Carbon Steel 90 Press Elbow 2x2

Product Description

The MUELLER INDUSTRIES CP02072 is a carbon steel 90-degree elbow with press-style connections on both ends, sized at 2 inches by 2 inches. It is designed for use in piping systems that require a right-angle change in direction without the need for open-flame soldering or welding. Rated to 200 psi and suitable for operating temperatures from -40 degrees F to 250 degrees F, this fitting handles demanding commercial and residential piping applications. Licensed plumbers and pipefitters install this type of fitting using press tooling, making it a fast and reliable option for closed or retrofit systems.

This elbow is suited for hydronic heating, chilled water, and general plumbing piping systems where press-fit connections are specified. The 2-inch by 2-inch sizing fits main-line runs commonly found in commercial mechanical rooms, multi-family residential builds, and light industrial installations. It is appropriate wherever carbon steel press fittings are called out on construction documents or used to replace existing fittings in kind.

Key Features

• 90-degree elbow configuration for right-angle direction changes in piping runs
• Press x Press end connections on both ends eliminate open-flame joining
• Carbon steel construction rated to 200 psi operating pressure
• Wide temperature range: -40 degrees F to 250 degrees F
• 2-inch by 2-inch end sizes suit main-line commercial and residential applications

Compatibility

Designed as an OEM-style press fitting for 2-inch carbon steel piping systems where press-style end connections are required.

Installation Notes

Installation must be performed by a licensed plumber or pipefitter using manufacturer-approved press tooling rated for the pipe and fitting diameter. Depressurize and drain the piping system completely before removing any existing fittings or making new connections. Verify that the pipe ends are clean, deburred, and properly inserted to the full depth mark before pressing. Follow applicable plumbing codes, including IPC requirements, for pressure testing after installation.

Technical Specifications

• Material: Carbon Steel
• End Type: Press
• End Size: 2 inches
• Second End Type: Press
• Second End Size: 2 inches
• Maximum Operating Pressure: 200 psi
• Minimum Operating Temperature: -40 degrees F
• Maximum Operating Temperature: 250 degrees F

Standard Information

• Brand: MUELLER INDUSTRIES
• Manufacturer Part Number: CP02072
