Mueller Industries 117-843 Solder Ball Valve With Packing Gland 1/2 in (MUELBVS12)

Product Description

Mueller Industries 117-843 is a 1/2 in solder x solder full-port brass ball valve with a packing gland for stem sealing. It is rated to operate from -20 F to 300 F (-29 C to 149 C) with a maximum operating pressure of 600 psi (41 bar) and includes PTFE seats and PTFE packing, a blowout-proof stem, and a lever handle with vinyl grip. Suitable for plumbing, HVAC, refrigeration and industrial systems.

• Full-port 1/2 in solder x solder brass ball valve with packing gland and lead-free CXC construction
• Temperature range -20 F to 300 F (-29 C to 149 C) and maximum operating pressure 600 psi (41 bar); rated 600 PSI WOG and 150 PSI SWP
• Forged brass body and ball, PTFE seats and packing, blowout-proof stem, lever handle with vinyl grip

Product Highlights

1/2 in full-port soldered ball valve; PTFE seats/packing; 600 psi max; -20 F to 300 F

Product Information

Standard Information

• Brand: MUELLER INDUSTRIES
• Manufacturer Part Number: 117-843

Technical Specifications

• Brand: Mueller Industries
• Manufacturer Part Number: 117-843
• Replacement MPN: MUELBVS12
• Series: 7700NL Series Brass Full Port Ball Valves
• Product Family: Mueller Streamline Solder with Packing Gland
• Type: Ball valve
• Size: 1/2 in
• Connection Type: SOLDER x SOLDER
• End Type: Female Solder
• End Size: 1/2 in
• Port Type: Full port (Full)
• Body Material: Brass (forged brass body)
• Ball Material: Forged brass
• Seat Material: PTFE
• Seal / Packing Material: PTFE packing
• Stem Features: Blowout-proof stem
• Handle Type: Lever handle with vinyl grip
• Packing Gland: Yes
• Lead Free: Yes (CXC lead-free brass)
• Operating Temperature: -20 F to 300 F (-29 C to 149 C)
• Operating Pressure (Max): 41 bar (600 psi)
• Pressure Rating WOG: 600 PSI WOG
• Pressure Rating SWP: 150 PSI SWP
• Weight: 0.40 lb
• Dimensions A: 3.74 in
• Dimensions B: 1.78 in
• Dimensions C: 0.59 in
• Dimensions D: 0.63 in
• Dimensions E: 0.50 in
• Dimensions F: 0.98 in
• Dimensions G: 1.97 in
• Certifications: UL, CSA, FM, CUPC, NSF/ANSI 61G/37
• Applications: Plumbing, HVAC, refrigeration, commercial, residential and industrial water and oil systems
• UPC: 685768451068
