Description

Product Description

Mueller AQ17862C is a Cyclemaster refrigeration ball valve with a 5/8 in outside diameter inlet and a 1/2 in ball port. It is brass constructed with a drilled and tapped access port for servicing and full-port flow to match line size ID. The valve features an internally equalized ball design, rupture-proof encapsulated stem, MCM seal technology, and is certified to UL/cUL and CE standards, suitable for refrigeration service.

  • 5/8 in outside diameter (ODS) connection with 1/2 in full port; brass construction and drilled/tapped access port
  • Working pressure: 700 psi; maximum pressure rating: 775 psi; operating temperature range: -40°F to 300°F
  • Internally equalized ball design, rupture-proof encapsulated stem, MCM Seal Technology; UL/cUL listed and CE certified

Product Highlights

5/8 in ODS connection; 1/2 in port; access port included; 700 psi working pressure; -40°F to 300°F; UL/cUL and CE certified

Product Information

Standard Information

  • Brand: MUELLER
  • Manufacturer Part Number: AQ17862C
  • Country of Origin: China
Technical Specifications
MPN
AQ17862C
Brand
Mueller
Series
Cyclemaster
Product Type
Ball valve (refrigeration)
Connection
5/8 in outside diameter (ODS)
Port Size
1/2 in (0.50 in)
Material
Brass
Connection Size
5/8 in
End Style
Solder / sweat compatible (ODS inlet)
Flow Coefficient (Cv)
12.10
Kv
10
Working Pressure
700 psi
Maximum Pressure
775 psi
Maximum Allowable Pressure (MAP)
53 bar (775 psi)
Operating Temperature Range
-40°F to 300°F (-40°C to 149°C)
Compatibility (refrigerants)
Compatible with CFC, HCFC and HFC refrigerants and oils
Access Port
Drilled and tapped access port included
Seal Technology
MCM Seal Technology
Design
Full port construction; internally equalized ball design
Stem
Rupture-proof encapsulated stem
Certifications
UL/cUL listed; CE certified
Weight
0.54 lb (0.24 kg)
Overall Length
6.35 in (161 mm)
Overall Width
0.87 in (22 mm)
Overall Height
2.23 in (57 mm)
Mounting Holes
Included; M4 x 0.7 metric
Mounting Hole-to-Hole Distance
0.9 in
Seal Cap Kit (compatible)
A17842
Category
HVAC / Refrigeration valve
Country of Origin
China
