MRCOOL MVP-36-HP-MUAH-230-00 MRCOOL VersaPro Central Ducted Air Handler

Product Description

The MRCOOL VersaPro Central Ducted Air Handler MVP-36-HP-MUAH-230-00 is suitable for heating and cooling in central split systems. This three-ton unit is made of painted galvanized steel and is designed to provide efficient airflow. It features a variable speed blower motor for better control of temperature and efficiency. The unit supports various airflow configurations including upflow, downflow, and horizontal setups.

• Cooling capacity of three tons.
• Compatible with heat strips up to fifteen kW.
• Supports multiple airflow configurations.

Product Highlights

This air handler is ideal for residential and commercial applications that require reliable heating and cooling performance.

Product Information

Standard Information

• Model: MVP-36-HP-MUAH-230-00
• Warranty: 10 Years Parts

Technical Specifications

• Cooling Capacity: 36,000 BTU
• Heating Capacity: 36,000 BTU
• Max Overcurrent Protection: 15 amps
• Refrigerant: R-410A
• Electrical Phase: 1-Phase
• Voltage: 240 V
• Variable Speed Blower Motor: Yes
• CFM: 1188.97/1083.02/971.19/865.24
• Decibel Rating Low: 28 DBA
• Decibel Rating High: 48 DBA
• Wifi Compatibility: Yes
