MRCOOL HHP15024FA MRCOOL HHP15024FA 2 Ton PRODIRECT Series Heat Pump Condenser

Product Description

The MRCOOL HHP15024FA is a two-ton heat pump condenser from the PRODIRECT series. It is suitable for both cooling and heating applications. This unit has a SEER2 rating of fifteen point two and uses R410A refrigerant.

• Constructed with durable inner-groove copper tubes and aluminum fins.
• Operates at a decibel rating of seventy-four dBA.
• Features service valves with sweat connections, accessible gauge ports, high and low-pressure switches.

Product Highlights

The MRCOOL HHP15024FA offers reliable performance for residential and commercial use.

Product Information

Standard Information

• Brand: MRCOOL
• MPN: HHP15024FA

Technical Specifications

• SEER2: 15.2
• Cooling Capacity (BTU): 24000
• Heating Capacity (BTU): 24000
• Input Voltage: 208/230
• Phase: 1
• Cycle: 60
• Max Fuse Breaker (A): 24
• Min Circuit Ampacity (A): 15.5
• Rated Load: 8
• Refrigerant Type: R410A
• Refrigerant Volume (oz): 103
• Decibel Rating (DBA): 74
• Liquid Line Size: 3/8
• Suction Line Size: 3/4
• Compressor Motor Type: Scroll
• Condenser Fan Motor Type: ECM
• Condenser Fan Motor HP: 1 1/6
• Net Depth (in): 28
• Net Height (in): 24 15/16
• Net Width (in): 28
• Net Weight (lbs): 154
