MRCOOL HAH024FPA 2 Ton ProDirect Series PSC Air Handler HAH024FPA

Product Description

The MRCOOL 2 Ton ProDirect Series PSC Air Handler, model HAH024FPA, is suitable for cooling and heat pump systems. It has an aluminum evaporator coil tube and features a corrosion-resistant design. The cabinet minimizes air leakage and supports multi-position installation.

• Cooling capacity is twenty-four thousand BTU.
• Includes both horizontal and vertical condensate drain pans.
• ETL Listed and AHRI certified.

Product Highlights

Reliable air handler for HVAC applications with efficient performance.

Product Information

Standard Information

• Brand: MRCOOL
• MPN: HAH024FPA

Technical Specifications

• Tonnage: 2
• Cooling Capacity: 24000 BTU
• SEER/EER: 15.2
• Voltage: 208/230V
• Phase: 1
• Cycle: 60
• Max Fuse Breaker (A): 15
• Min Circuit Ampacity (A): 2.9
• Refrigerant Type: R410a
• Liquid Line Size: 3/8
• Suction Line Size: 3/4
• Blower Motor Type: PSC
• Blower Motor HP: 1/4
• Blower Motor RPM: 903
• Net Depth: 21 5/8
• Net Height: 46 1/2
• Net Width: 19 5/8
• Net Weight: 128
• Certifications: AHRI Listed & ETL Certified
• Evaporator Coil Material: Aluminum
• Evaporator Coil Tube Size: 9/32 inches
