DESCRIPTION:

The MRCOOL 4th Generation DIY 18K BTU Ductless Wall Mounted Air Handler is one of the most capable on the market. When part of a MRCOOL DIY system, it can reach an effective 22 SEER efficiency rating and deliver that performance to an area up to 750 sq. ft. This air handler is also very versatile because of its many different operating modes; these include COOL, HEAT, AUTO, DRY (dehumidify), and SLEEP. It also has the ability to be controlled from anywhere using an Apple or Android smartphone with our convenient Smart HVAC app. This air handler is very compact and relatively light, so it can easily be mounted to most interior walls using the included mounting plate. The ease of installation does not stop there, as it is designed to be used along with the MrCool Pre-Charged Quick Connect Line Set. This allows the installer to easily connect the refrigerant piping, which is precharged with the correct amount of R-410A refrigerant, with the use of simple hand tools. This also means the system will not require any vacuuming once the line set is connected. The MrCool DIY 18K BTU Ductless Wall Mounted Air Handler has the performance to handle your home comfort needs.

FEATURES:

• SmartHVAC app: WIFI Control (Compatible with Amazon Alexa and Google Assistant)
• Includes the new DIY Pro Cable: Added safety feature to protect the wiring from  outside elements
• Fan-only Option, Quiet Mode, and Auto Cool
• Inverter: regulates the speed of the compressor motor to adjust the temperature
• Remote Control Included
• Energy Star Certified, AHRI Certified
• Standard limited 7-year compressor/5-year parts warranty; register for limited lifetime compressor warranty


SPECIFICATIONS:

• Cooling capacity: 18,000 BTU
• Heating capacity: 18,000 BTU
• Voltage: 208-230 V
• Phase: 1
• Cycle: 60 Hz
• Mount Type: Wall
• Max Coverage Area:  Up to 750 sqft
• Refrigerant Type: R-410A
• Decibel Rating:  44.5/37/31
• Decibel Rating High:  44.5 dBA, Decibel Rating Low:  31 dBA
• Liquid Line Size: 1/4 in
• Suction Line Size: 1/2 in
• Max Lineset Length: 98.42 ft
• Blower Motor RPM:  1120/950/700
• Net Dimensions (in): H 13.19", W 42.52", D 8.90"
• Net Weight: 34.61 lbs
• Gross Dimensions (in): H 17.32", W 49.09", D 19.57"
• Gross Weight: 56 lbs
• Color: White
• Total Weight Approximation: 90.61 lbs
