MRCOOL CENTRAL-48-HP-230-00 Central Ducted Heat Pump Condenser

Product Description

The MRCOOL CENTRAL-48-HP-230-00 is a central ducted heat pump condenser that provides efficient heating and cooling. This unit features DC inverter and variable speed technology, making it adaptable to various conditions. It is constructed from durable painted galvanized steel and operates using R-410A refrigerant. The model can handle extreme temperatures between minus twenty-two degrees Fahrenheit to one hundred twenty-two degrees Fahrenheit.

• DC inverter and variable speed operation
• Compatible with MRCOOL No-Vac Quick Connect Line Sets and standard fittings
• Temperature range: -22°F to 122°F

Product Highlights

This heat pump is designed for central split systems, effectively covering areas of up to 2,000 square feet.

Product Information

Standard Information

• Model: CENTRAL-48-HP-C-230-00
• MPN: CENTRAL-48-HP-230-00

Technical Specifications

• Cooling Capacity: 47,000 BTU
• Heating Capacity: 50,000 BTU
• SEER2: 15.6
• EER2: 8.2
• HSPF2: 9.4/7.7
• Voltage: 208V-230V
• Electrical Phase: 1
• Cycle: 60 Hz
• Max Fuse Breaker: 50 amps
• Min Circuit Ampacity: 42 amps
• Refrigerant Type: R410A
• Refrigerant Volume: 169.32 oz
• Decibel Rating: 64 dB-A
• Inverter System: DC
• Product Width: 37.48 inches
• Product Length: 16.34 inches
• Product Height: 52.48 inches
• Weight: 248.68 lbs
• Warranty: 10 Year Parts and Labor
